Stairs Stairs XD Series Submersible Drainage

Stairs XD Series

All stainless steel submersible drainage and sump pump with open impeller for grey water applications

Suitable for:DomesticCommercial

2-year warranty as standard, excluding consumables

Specifications

Models
XD-07 / XD-10 / XD-15
Power
0.55 - 1.1 kW
Flow Rate
Up to 375 l/min (22.5 m³/h)
Total Head
Up to 16.1 m
Voltage
1~ 230 V with float switch, or 3~ 230 V / 400 V
Float Switch
Included on single-phase models
Max Solids
8 mm
Max Temp
+50 °C
Protection
IP68
Material
Stainless Steel
Impeller
Open, stainless steel
Seal
Mechanical + Oil Seal (SiC)
Discharge
1½"

Available Sizes

ModelkW / HPOutletSolidsMax FlowMax Head
XD-070.55 / 0.751½"8 mm250 l/min10.9 m
XD-100.75 / 1.01½"8 mm325 l/min14 m
XD-151.1 / 1.51½"8 mm375 l/min16.1 m

Description

The Stairs XD Series is an all stainless steel submersible drainage and sump pump designed for grey water and pure water transferring applications. Equipped with an open stainless steel impeller capable of passing 8 mm solids, at up to 375 l/min and 16.1 m head, and handles liquids up to +50 °C. The combination of stainless steel shaft and oil-filled lip seal with silicon carbide mechanical seal, plus double-shielded ball bearings, delivers an extremely long operating life. Double seal design (mechanical seal + oil seal) improves bearing lubrication and prevents leaking. Three models, the XD-07, XD-10 and XD-15, from 0.55 kW to 1.1 kW. Single-phase versions come with a float switch and a built-in thermal protector; three-phase versions are available in 230 V or 400 V.
