PowerBox Eco
Economy packaged pressure booster - 300L or 500L tank with Divertek pump and external controller
2-year warranty as standard, excluding consumables
Specifications
- Tank
- 300L or 500L
- Pump
- Divertek 650
- Control
- External controller, outside the tank
- Pressure Vessel
- In the controller
- Power
- 0.42 kW / 0.56 HP
- Voltage
- 230 V
- Current
- 2.9 A
- Fuse
- 6 A
- Max Flow
- 100 l/min
- Max Head
- 30 m
- Max Pressure
- 3 bar
- Dimensions (Ø × H)
- 630 × 1170 mm (300L) / 700 × 1460 mm (500L)
- Vessel Air Charge
- 1.5 - 1.8 bar
Description
The PowerBox Economy is a complete storage and pressure package for homes and light commercial buildings with low or unreliable mains pressure. A 300L or 500L tank, submersible pump, controls and acoustic pad come pre-plumbed. The tank fills from the incoming mains and the pump delivers the stored water to every tap and shower at up to 3 bar and 100 l/min. On the Economy, a Divertek 650 pump runs from an external controller outside the tank, with the pressure vessel built into the controller, keeping the cost down. The pump sits underwater on an acoustic pad, so it runs quietly and never needs priming, and it starts and stops on demand with dry-run protection. Pumps and controllers are also sold separately, for replacement or for retrofitting an existing tank.
