Stairs ST-10 Series
4" stainless steel borehole pump for household supply and farms - three models, up to 139 m head
2-year warranty as standard, excluding consumables
Documentation
Specifications
- Models
- ST-1010 / ST-1014 / ST-1020
- Best For
- Household supply and farms
- Power Range
- 0.55 - 1.1 kW (0.75 - 1.5 HP)
- Max Flow
- 50 l/min
- Max Head
- 139 m
- Outlet
- 1¼"
- Material
- AISI 304 SS
- Max Water Temp
- +35 °C
Available Sizes
| Model | Motor kW / HP | Outlet | Max Flow | Max Head |
|---|---|---|---|---|
| ST-1010 | 0.55 / 0.75 | 1¼" | 50 l/min | 67 m |
| ST-1014 | 0.75 / 1.0 | 1¼" | 50 l/min | 92 m |
| ST-1020 | 1.1 / 1.5 | 1¼" | 50 l/min | 139 m |
Description
The Stairs ST-10 Series is a 4" stainless steel submersible borehole pump for household supply and farms. Three models, from the ST-1010 to the ST-1020, deliver up to 50 l/min at heads up to 139 m. 304 stainless steel bowls and discharge head are built to last, a built-in non-return valve keeps the rising main full, and a machined stainless NEMA adaptor with a 304 shaft coupling locks the pump to its motor. Every model has a standard 1¼" threaded outlet. Each pump is matched to a Stairs 4" motor and control box and supplied as a set, ready to install.
